| 起源の場所: | 中国 |
| ブランド名: | Mettler Toledo |
| モデル番号: | 計量モジュール SWB805 316 4.4T/10K C1 |
| 最小注文数量: | 1セット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | カロンボックス |
| 受渡し時間: | 10~30日 |
| 供給の能力: | 月額2000セット |
| 製品: | メトラー・トレド ロードセル | 最大容量: | 10千ポンド (4,400 kg) |
|---|---|---|---|
| 素材: | 316 ステンレス | 度量衡学: | NTEP III 1.6 M オイムL C1 |
| 負荷セル: | SLB815 | 精度: | 低い |
| 保護評価: | IP68/69k | 環境 / 材料: | 頻繁な洗浄/衛生的 |
| 危険物承認: | ATEX, FM, cFM | 重要度: | 標準 |
| ケーブル: | 5つのm | ||
| ハイライト: | 316 stainless steel weigh module,high-accuracy 10K load cell,Mettler Toledo 4.4T load cell |
||
Our weigh module is designed according to hygienic principles and certified by NSF, reducing contamination risk to a minimum.
Increased efficiency thanks to highly-polished, self-draining surfaces that clean and dry quickly. Visual inspection is easy due to the open design.
Our weigh modules are shipped in a locked position and can be integrated without interfering with the sealing, thus no risk of contamination.
A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales, and in tank, hopper and silo weighing. Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons.
| Attribute | Value |
|---|---|
| Product | Mettler Toledo Load Cell |
| Maximum Capacity | 10,000 lb (4,400 kg) |
| Material | 316 Stainless steel |
| Metrology | NTEP III 1.6 M OIML C1 |
| Load Cell | SLB815 |
| Accuracy | Low |
| Protection Rating | IP68/69k |
| Environment / Material | Frequent wash-down / Hygienic |
| Hazardous Approval | ATEX, FM, cFM |
| Criticality | Standard |
| Cable | 5 m |
