| 起源の場所: | 中国 |
| ブランド名: | Mettler Toledo |
| モデル番号: | ロードセル SLP332D-IOL-100kg C3/5k |
| 最小注文数量: | 1 セット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | カロンボックス |
| 受渡し時間: | 10~30日 |
| 供給の能力: | 月額2000セット |
| 製品: | メトラー・トレド ロードセル | 最大容量: | 220ポンド (100 kg) |
|---|---|---|---|
| 材料: | アルミニウム、不動態化 | メトロロジー: | NTEP III 5,000d OIML C3 |
| 精度: | スタンダード | 保護評価: | IP67 |
| 危険物承認: | ATEX, FM | 重要度: | 標準 |
| プラットフォームサイズ (長さ x 幅): | 400 mm x 400 mm | 接続性: | 統合 |
| ハイライト: | 100kg IO-Link load cell,digital force sensor for industrial weighing,SLP332D-IOL load cell with warranty |
||
A high-performance compression weigh module designed for industrial applications where its top plate and base plate are compressed when weight is applied. This load cell can be directly attached to the ground, piers, or structural beams, making it ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing systems.
| Attribute | Value |
|---|---|
| Product | Mettler Toledo Load Cell |
| Maximum Capacity | 220 lb (100 kg) |
| Material | Aluminum, passivated |
| Metrology | NTEP III 5,000d OIML C3 |
| Accuracy | Standard |
| Protection Rating | IP67 |
| Hazardous Approval | ATEX, FM |
| Platform Size (LxW) | 400 mm x 400 mm |
| Connectivity | Integrated |
The SLP33xD-IOL load cells connect directly to any automation systems via IO-Link, eliminating the need for additional electronic units.
Standard cables and connectors reduce installation complexity. Factory calibration ensures immediate startup and operation.
Continuous condition monitoring with alarms according to NAMUR NE 107 standards results in higher machine uptime and increased productivity.
