| Place of Origin: | CHINA |
| Model Number: | Checkweigher Integration in Packaging Lines |
| Minimum Order Quantity: | 1 set |
|---|---|
| 価格: | 交渉可能 |
| Packaging Details: | Caron box |
| Delivery Time: | 10-30days |
| Supply Ability: | 2000 set per month |
| 製品: | パッケージングラインの統合をチェックします | コンベア幅: | 200–1200mm |
|---|---|---|---|
| ベルト速度同期: | 5〜120 m/min | 製品間隔: | 分アイテム間の50mm |
| 電源: | 400V/50Hzまたは480V/60Hz | I/O信号: | 24VDC（最小16DI/8DO） |
| 通信プロトコル: | イーサネット/IP、Profinet、Modbus TCP | 精度クラス: | y（b）からy（a）（0.1g – 0.001g） |
| 最大スループット: | 50〜800アイテム/分 | 拒否タイプ: | 空気圧/エアナイフ/ダイバーター |
| 拒否速度: | <10msアクティベーション時間 | データサンプリングレート: | 500〜1000Hz |
| ERP/MES接続: | SAP/Oracle/Rockwell | 動作温度: | 0〜50°C |
| IP評価: | IP54 – IP69K | 安全整合性レベル（SIL）: | SIL-2 |
| 緊急停止反応: | <500msフルストップ | ||
| ハイライト: | automated checkweighing machine,automatic checking weigher for manufacturing,precision checkweigher |
||
| Attribute | Value |
|---|---|
| Conveyor Width | 200–1200mm |
| Belt Speed Synchronization | 5–120 m/min |
| Product Spacing | Min. 50mm between items |
| Power Supply | 400V/50Hz or 480V/60Hz |
| I/O Signals | 24VDC (16DI/8DO minimum) |
| Communication Protocols | Ethernet/IP, PROFINET, Modbus TCP |
| Accuracy Class | Y(b) to Y(a) (0.1g–0.001g) |
| Maximum Throughput | 50–800 items/min |
| Rejection Type | Pneumatic/Air Knife/Diverter |
| Rejection Speed | <10ms activation time |
| Data Sampling Rate | 500–1000Hz |
| ERP/MES Connectivity | SAP/Oracle/Rockwell |
| Operating Temperature | 0–50°C |
| IP Rating | IP54–IP69K |
| Safety Integrity Level (SIL) | SIL-2 |
| Emergency Stop Reaction | <500ms full stop |
Modern packaging lines increasingly incorporate automated checkweighers as mission-critical quality control stations that verify product weight compliance while maintaining production flow. Proper integration ensures:
Properly integrated checkweighers become neural hubs in smart packaging lines, delivering both quality assurance and operational intelligence. The integration strategy must balance mechanical precision, data integrity, and production ecology to achieve true Industry 4.0 performance.
